Deep Well Water Level Sensor
The Deep Well Water Level Sensor produced by Wepower Electronic has won the favor of customers from all over the world with its high quality and high cost performance.
Structure Of Deep Well Water Level Sensor :
Deep Well Water Level Sensor is ideal well depth measuring tape sensor , the deep well water level sensor is portable instrument which can be also used for measuring water levels in deep wells, boreholes, borewells , standpipes and other drilling process . As the obvious advantages ,such as low product price , easy to carry everywhere, easy to operate , simple structure , this deep well water level sensor can not be replaced in the related fields . Deep well water level sensor detects water levels with a (14mm*220mm) stainless steel weighted probe, durable polyethylene tape marked to mm scale , circuit board electronics , reel disc ; while the range reaches 400m , deep well level sensor comes with wheel trolley for convenient carrying .
Features Of Deep Well Water Level Sensor:
- Precision measurement, simplicity, durability
- Polycarbonate sturdy stainless steel ruler
- Corrosion-resistant stainless steel fittings
- Self-contained power supply using a standard, small 9V battery
- Water and dust-proof encapsulated electronics
- Full depth stainless steel probe
- Tape marked in 1 foot and 0.01 foot intervals
| Product Name | Deep Well Water Level Sensor |
| Measure Range (m) | WCL-30m,WCL-50m,WCL1-00m,WCL-150m,WCL-200m,WCL-250m,WCL-300m, WCL-350m ,WCL-400m, WCL500m, etc |
| Minimum Indication(mm) | 1 mm |
| Repeat Indication (mm) | ±2.0 |
| Power Supply(V) | 9V Lithium Battery |
| Probe Dimension | 14*220mm;(Dia16mm can be offered too) |
| Material | ● ABS Reel and handle ,Metal frame (Range less than 350m )
● Metal reel , Metal Handle , Metal Frame (Range≥ 400m ) ● Metal reel , metal handle ,Metal Frame ,with wheel trolley (Range=500m) |
| Cable Material /Size | Steel ruler with PE Coating ; Width: 12mm * Thickness 2mm |
| Ambient Temperature | -20~65°C, relative humidity ≤90%, no condensed water, no strong magnetic field interference |
| Indication Way | Indicator Light, Buzzer when the probe makes contact with water |
| Product Size | Length 36cm * Width 26cm * Height 44cm |
| Weight | 5KGS (50m )/ 10KGS(300m) /23KGS(500m) |
| Reel Disc Color | Yellow / Blue |
